Our Construction Hoists- Bocker MX624
Bocker MX624
The Bocker MX624 is a robust and versatile hoist and can be configured to carry passengers and materials, with a total capacity of up to 650kg or 4 persons.
The compact design offers a modular platform, with a single mast providing convenience on site and allowing tightspaced installations without compromising on performance. There is also a C gate option available as well, allowing for further versatility and to allow your needs on site to be met.
| Max Capacity (Kg) | L | W | H | Max Passengers | Configuation | Machine Name | Enquire | |
|---|---|---|---|---|---|---|---|---|
| 300 | 1.40 | 0.85 | 2.00 | N/A | - | Bocker Z320 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=300kg&Length=1.40&Width=0.85&Height=2.00#specific |
| 300 | 1.40 | 0.85 | 2.00 | N/A | - | Bocker MX320 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=300kg&Length=1.40&Width=0.85&Height=2.00#specific |
| 500 | 1.45 | 1.65 | 2.00 | N/A | - | GEDA 500Z | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=500kg&Length=1.45&Width=1.65&Height=2.00#specific |
| 650 | 1.70 | 1.40 | 1.80 | N/A | A17 | Bocker MX624 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=650kg&Length=1.70&Width=1.40&Height=1.80#specific |
| 1000 | 1.70 | 1.40 | 1.80 | N/A | A17 | Bocker MX1024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1000kg&Length=1.70&Width=1.40&Height=1.80#specific |
| 1200 | 4.25 | 1.40 | 1.80 | N/A | A42 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1200kg&Length=4.25&Width=1.40&Height=1.80#specific |
| 1200 | 5.10 | 1.40 | 1.80 | N/A | A51 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1200kg&Length=5.10&Width=1.40&Height=1.80#specific |
| 1200 | 1.70 | 4.50 | 1.80 | N/A | B45 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1200kg&Length=1.70&Width=4.50&Height=1.80#specific |
| 1500 | 1.70 | 1.40 | 1.80 | N/A | A17 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1500kg&Length=1.70&Width=1.40&Height=1.80#specific |
| 1500 | 2.50 | 1.40 | 1.80 | N/A | A25 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1500kg&Length=2.50&Width=1.40&Height=1.80#specific |
| 1500 | 3.40 | 1.40 | 1.80 | N/A | A34 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1500kg&Length=3.40&Width=1.40&Height=1.80#specific |
| 1500 | 1.70 | 3.00 | 1.80 | N/A | B30 | Bocker MX1524 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1500kg&Length=1.70&Width=3.00&Height=1.80#specific |
| 1600 | 2.50 | 2.90 | 1.80 | N/A | ED Plus | GEDA 1500Z | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1600kg&Length=2.50&Width=2.90&Height=1.80#specific |
| 1700 | 4.25 | 1.40 | 1.80 | N/A | A42 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1700kg&Length=4.25&Width=1.40&Height=1.80#specific |
| 1700 | 5.10 | 1.40 | 1.80 | N/A | A51 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1700kg&Length=5.10&Width=1.70&Height=1.80#specific |
| 1700 | 1.70 | 4.50 | 1.80 | N/A | B45 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1700kg&Length=1.70&Width=4.50&Height=1.80#specific |
| 1700 | 4.25 | 1.40 | 1.80 | N/A | A42 | Bocker LX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1700kg&Length=4.25&Width=1.40&Height=1.80#specific |
| 1700 | 5.10 | 1.40 | 1.80 | N/A | A51 | Bocker LX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=1700kg&Length=5.10&Width=1.40&Height=1.80#specific |
| 2000 | 1.70 | 1.40 | 1.80 | N/A | A17 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=1.70&Width=1.40&Height=1.80#specific |
| 2000 | 2.50 | 1.40 | 1.80 | N/A | A25 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=2.50&Width=1.40&Height=1.80#specific |
| 2000 | 3.40 | 1.40 | 1.80 | N/A | A34 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=3.40&Width=1.40&Height=1.80#specific |
| 2000 | 1.70 | 3.00 | 1.80 | N/A | B30 | Bocker MX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=1.70&Width=3.00&Height=1.80#specific |
| 2000 | 1.65 | 2.90 | 1.80 | N/A | E | GEDA 1500Z | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=1.65&Width=2.90&Height=1.80#specific |
| 2000 | 1.65 | 2.90 | 1.80 | N/A | ED | GEDA 1500Z | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=1.65&Width=2.90&Height=1.80#specific |
| 2000 | 1.65 | 4.35 | 1.80 | N/A | G | GEDA 1500Z | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=1.65&Width=4.35&Height=1.80#specific |
| 2000 | 1.65 | 4.35 | 1.80 | N/A | GD | GEDA 1500Z | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=1.65&Width=4.35&Height=1.80#specific |
| 2000 | 2.55 | 1.40 | 1.80 | N/A | A25 | Bocker LX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=2.55&Width=1.40&Height=1.80#specific |
| 2000 | 3.40 | 1.40 | 1.80 | N/A | A34 | Bocker LX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2000kg&Length=3.40&Width=1.40&Height=1.80#specific |
| 2300 | 1.70 | 1.40 | 1.80 | N/A | A17 | Bocker LX2024 | > | https://ntp-group.com/contact-us/?Hoist_type=Goods&swl=2300kg&Length=1.70&Width=1.40&Height=1.80#specific |
